As a premier Chinese exporter specializing in factory-direct FRP cooling solutions, our DBNL3J-70 cross-flow cooling tower is engineered to solve the critical challenge of thermal management in high-capacity industrial recirculating water systems, particularly for thermal power plants and large-scale HVAC central air-conditioning projects. Unlike standard models, this unit features a heavy-duty corrosion-resistant FRP shell and an optimized fill design that sustains thermal performance even in dusty or saline coastal environments, ensuring a 12-15°C temperature drop under 70 nominal tons of load. By eliminating intermediary markups, we offer international buyers a transparent, bulk-export pricing structure coupled with rigorous workshop performance testing (thermal rating verification) and customized voltage options for global compatibility, positioning your project for a 20% reduction in long-term maintenance costs while meeting strict environmental discharge noise standards.
كتيب منتجات شركة هيبي فورتيس للتكنولوجيا المحدودة
Product Advantages
Structural Integrity with Maritime-Grade FRP Shell
The DBNL3J-70 is fabricated using a flame-retardant, UV-stabilized FRP laminate that incorporates an additional gel-coat thickness of 0.5mm – exceeding standard industry practice. This shell formulation is specifically engineered to withstand not only internal chemical attack from pH-fluctuating recirculated water but also external saline mist, airborne fly ash, and industrial fumes commonly found in coastal power stations and steel sintering plants. The result is zero surface chalking or micro-cracking after 8–10 years of outdoor exposure, eliminating the need for costly periodic repainting or panel patching that plagues metallic towers.
Gravity-Flow Water Distribution for Unmatched Pumping Economy
Unlike forced-spray nozzles that require higher pump head pressure, the DBNL3J-70 employs a large-basin, gravity-fed distribution system with anti-clogging orifices (25mm diameter). This design reduces the required pumping head by approximately 2.5–3.0 meters compared to conventional counter-flow equivalents, directly translating to 12–15% lower annual electricity consumption on your circulating pump set. Furthermore, the open-basin structure allows for rapid visual inspection of water flow even during full-load operation, enabling your shift operators to spot uneven distribution or debris accumulation within seconds without any tools.
Drift Eliminator with Sub-0.001% Water Loss Rate
Our proprietary three-pass zig-zag drift eliminators, manufactured from high-impact PVC, are recessed into the tower exit duct to maximize capture surface area without increasing pressure drop. Independently tested at 110% of design air velocity, these eliminators guarantee water carryover below 0.001% of the recirculation rate – a critical metric for plants operating under strict water consumption permits or those using expensive demineralized make-up water. This feature alone can save up to 150–200 cubic meters of water annually per 70-ton unit, directly supporting your corporate ESG (Environmental, Social, and Governance) reporting targets.
Parameter Specifications
|
Product |
Low Noise collecting Type Counterflow FRP Cooling Tower |
|||||||||
|
|
||||||||||
|
Model |
τ=27℃ |
Main Dimensions (mm) |
Air Volume m³/h |
Fan Diameter (mm) |
Motor Power (kw) |
weight (kg) |
inlet pressure 10⁴Pa |
noise at 10m dB (A) |
||
|
Total Height |
Maximum Diameter |
self-weight |
operating weight |
|||||||
|
DBNL3J-12 |
15 |
2333 |
1210 |
7200 |
700 |
0.6 |
217 |
775 |
1.96 |
40.3 |
|
DBNL3J-20 |
24 |
2423 |
1460 |
12400 |
800 |
0.8 |
244 |
958 |
2 |
41.1 |
|
DBNL3J-30 |
35 |
2642 |
1912 |
18000 |
1200 |
0.8 |
424 |
1734 |
2.21 |
43.5 |
|
DBNL3J-40 |
46 |
3142 |
1912 |
21500 |
1200 |
1.1 |
496 |
1896 |
2.6 |
43.5 |
|
DBNL3J-50 |
57 |
3130 |
2215 |
28000 |
1400 |
1.5 |
617 |
2505 |
2.65 |
44.7 |
|
DBNL3J-60 |
68 |
3430 |
2215 |
32300 |
1400 |
1.5 |
667 |
2829 |
2.78 |
45.7 |
|
DBNL3J-70 |
79 |
3444 |
2629 |
39200 |
1600 |
2.2 |
824 |
3816 |
3.03 |
47 |
|
DBNL3J-80 |
92 |
3744 |
2629 |
43400 |
1600 |
2.2 |
909 |
4240 |
2.86 |
47.5 |
|
DBNL3J-100 |
114 |
3694 |
3134 |
56000 |
1800 |
3 |
1014 |
5932 |
3.15 |
50 |
|
DBNL3J-125 |
142 |
3944 |
3134 |
67200 |
1800 |
4 |
1104 |
6158 |
3.15 |
50.7 |
|
DBNL3J-150 |
171 |
3953 |
3732 |
84000 |
2400 |
4 |
1744 |
8246 |
2.9 |
52 |
|
DBNL3J-175 |
200 |
4203 |
3732 |
94300 |
2400 |
5.5 |
1884 |
8582 |
3.15 |
53 |
|
DBNL3J-200 |
231 |
4235 |
4342 |
112000 |
2800 |
5.5 |
2208 |
11210 |
3.01 |
54.6 |
|
DBNL3J-250 |
283 |
4485 |
4342 |
134300 |
2800 |
7.5 |
2420 |
11983 |
3.26 |
55.6 |
|
DBNL3J-300 |
334 |
4623 |
5134 |
168000 |
3400 |
11 |
3648 |
17173 |
3.5 |
56.8 |
|
DBNL3J-350 |
395 |
4873 |
5134 |
187400 |
3800 |
11 |
3950 |
17850 |
3.75 |
57.3 |
|
DBNL3J-400 |
455 |
5018 |
6044 |
224000 |
3800 |
11 |
4406 |
23132 |
3.6 |
58.8 |
|
DBNL3J-450 |
514 |
5268 |
6044 |
242000 |
3800 |
11 |
4752 |
24510 |
3.85 |
58.8 |
|
DBNL3J-500 |
576 |
5619 |
6746 |
280000 |
4200 |
15 |
5887 |
30062 |
3.7 |
60 |
|
DBNL3J-600 |
680 |
6119 |
6746 |
302200 |
4200 |
18.5 |
6689 |
32164 |
4.2 |
61 |
|
Features |
The FRP cooling tower serves not only as a temperature regulator but also delivers an efficient, durable, and maintenance-free solution with optimized lifecycle costs. By harnessing the unique properties of FRP materials, it fundamentally addresses the critical challenges of corrosion and lifespan limitations in harsh operating environments, making it the go-to choice for cooling systems in modern industrial and commercial facilities. |
|||||||||
|
Application
|
Central air conditioning system: refrigeration station for commercial buildings, hotels and hospitals. |
|||||||||
|
Industrial refrigeration: process cooling for food processing, chemical, pharmaceutical and plastic industries. |
||||||||||
|
Power industry: auxiliary cooling system for thermal power plant and nuclear power plant. |
||||||||||
|
Manufacturing industry: circulating water cooling for metallurgical and mechanical processing plants. |
||||||||||
|
Data center: Provides cooling water for server rooms. |
||||||||||
|
Payment |
T/T, Western Union. |
|||||||||
|
Service |
Customize and design the size and style according to requirements |
|||||||||
