We are a China-based factory-direct manufacturer and exporter of FRP utility poles, serving power distribution, telecommunications, coastal and renewable energy projects worldwide. Our pultruded fiberglass poles are lightweight, corrosion-resistant, non-conductive and engineered to withstand harsh environments where traditional wood, steel or concrete poles fail. As an experienced FRP pole supplier, we offer customizable lengths, diameters, wall thicknesses and colors, with IEC, ASTM and ISO-compliant production. Buyers sourcing utility poles from China choose us for stable quality, competitive factory pricing, flexible MOQs and reliable export logistics. Contact us for samples, specifications or a tailored quotation.Our company specializes in the manufacture and export of FRP utility poles from China, with a focus on factory-direct supply for overseas utilities, EPC contractors and telecom integrators. We produce fiberglass-reinforced polymer poles that resist corrosion, UV degradation and electrical conductivity, making them suitable for power lines, communication networks, coastal installations and solar farm infrastructure. Every pole is pultruded under controlled process parameters, and we support custom tooling, private labeling and mixed-container shipments. If you are looking for a dependable FRP utility pole exporter and long-term supplier, our team is ready to support your project from specification to delivery.
كتيب منتجات شركة هيبي فورتيس للتكنولوجيا المحدودة
Product Advantages
Superior Corrosion Resistance for Harsh Environments
FRP utility poles are engineered to resist corrosion far better than traditional wood, steel or concrete poles. Fiberglass-reinforced polymer does not rust, rot, or degrade when exposed to moisture, salt spray, chemicals or soil acids. This makes them particularly suitable for coastal regions, industrial zones, wastewater facilities and areas with high humidity, where conventional poles often require frequent replacement or protective treatment. The result is a longer service life and significantly lower maintenance costs over time.
Lightweight Yet High Strength
Despite weighing roughly one-quarter to one-third of an equivalent concrete pole, FRP utility poles deliver impressive mechanical strength. The pultruded fiberglass structure provides high tensile and flexural strength, allowing the pole to withstand wind loads, ice accumulation and mechanical stress. Because they are lightweight, they are easier to transport, handle and install, reducing the need for heavy lifting equipment and cutting installation time and labor costs, especially in remote or difficult-to-access locations.
Excellent Electrical Insulation
Unlike steel or concrete, FRP utility poles are naturally non-conductive. This inherent electrical insulation improves safety for linemen and maintenance crews working on or near live power lines. It also reduces the risk of electrical leakage, grounding issues and short circuits caused by conductive poles. For power distribution and telecom applications, this property adds a critical layer of protection that traditional materials cannot offer without additional insulation measures.
|
Product |
FRP Utility pole / telephone pole |
|||
|
Category |
Item |
Performance Requirements |
||
|
Mechanical Properties |
Tensile Strength |
≥500 MPa |
||
|
Flexural Strength |
≥500 MPa |
|||
|
Compressive Strength |
≥300 MPa |
|||
|
Physical Properties |
Flame Resistance |
V-1/0 Grade |
||
|
Chemical Resistance |
Acid Resistance (80°C, 5wt% HCl solution, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥80% |
||
|
Alkali Resistance (80°C, 10wt% NaOH solution, 7 days) |
No powdering, no cracks, flexural modulus retention rate ≥50% |
|||
|
Salt Resistance (80°C, 3wt% NaCl solution, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
|||
|
Aging Resistance |
Artificial Climate Aging (Method A-1, irradiance, cycle 1, 300h) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
||
|
Hygrothermal Aging (60°C, 93%RH, 12h~25°C/93%RH, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
|||
|
Constant Humidity and Heat Aging (60°C/93%RH, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
|||
|
High-Temperature Resistance (300°C~400°C) |
No powdering, no cracks, flexural modulus retention rate ≥80% |
|||
|
Electrical Properties |
Surface Resistivity |
≥1.0 × 10^10 Ω |
||
|
Volume Resistivity |
≥1.0 × 10^10 Ω•m |
|||
|
Density |
solid |
≤0.25 g/cm³ |
||
|
hollow |
≤2 g/cm³ |
|||
|
Model |
Length (m) |
Top Diameter (mm) |
Standard load (P) |
Standard bending moment (kN.m) |
|
Z Ø190×8×I×FH |
8 |
190 |
3 |
19.35 |
|
Z Ø190×9×I×FH |
9 |
190 |
3 |
21.75 |
|
Z Ø190×10×I×FH |
10 |
190 |
3 |
24.15 |
|
Z Ø190×12×I×FH |
12 |
190 |
3 |
29.25 |
|
Z Ø190×15×I×FH |
15 |
190 |
3 |
36.75 |
|
Z Ø190×18×I×FH |
18 |
190 |
3 |
/ |
|
Z Ø190×8×K×FH |
8 |
190 |
4 |
25.80 |
|
Z Ø190×9×K×FH |
9 |
190 |
4 |
29.00 |
|
Z Ø190×10×K×FH |
10 |
190 |
4 |
32.20 |
|
Z Ø190×12×K×FH |
12 |
190 |
4 |
39.00 |
|
Z Ø190×15×K×FH |
15 |
190 |
4 |
49.00 |
|
Z Ø190×18×K×FH |
18 |
190 |
4 |
61.00 |
|
Z Ø190×8×M×FH |
8 |
190 |
6 |
38.70 |
|
Z Ø190×9×M×FH |
9 |
190 |
6 |
43.50 |
|
Z Ø190×10×M×FH |
10 |
190 |
6 |
48.30 |
|
Z Ø190×12×M×FH |
12 |
190 |
6 |
58.50 |
|
Z Ø190×15×M×FH |
15 |
190 |
6 |
73.50 |
|
Z Ø190×18×M×FH |
18 |
190 |
6 |
91.50 |
|
Z Ø230×8×M×FH |
8 |
230 |
6 |
38.70 |
|
Z Ø230×9×M×FH |
9 |
230 |
6 |
43.50 |
|
Z Ø230×10×M×FH |
10 |
230 |
6 |
48.30 |
|
Z Ø230×12×M×FH |
12 |
230 |
6 |
58.50 |
|
Z Ø230×15×M×FH |
15 |
230 |
6 |
73.50 |
|
Z Ø230×18×M×FH |
18 |
230 |
6 |
91.50 |
